25W 10-16V DC to 115VAC Inverter circuit

This  power inverter uses only 9 electronic components. This inverter circuit will turn 10 to 16VDC into 115V / 60Hz square wave AC power. It was able to operate AC equipment up to 25W.

25W Inverter circuit

The first section of the 555 timer is wires as an astable oscillator with R2 and C1 setting the frequency. The output is available at pin 5. The second section is wired as a phase inverter. That output is available at pin 9. Resistor R3 and R4 keep output transistor Q1 and Q2 from loading down the oscillator.

Read more about 25W Inverter circuit

How does using two transistors instead of one make a circuit work better?

This is my GCSE science work, I looked all over the internet, but can’t find information on this topic, are there any sites out there, which have pictures of circuits with two transistors.

Transistors?

I need to asses what effect Transistors have on society, but i’m not quite sure what devices they’re used in.

Are they used in _______
- Television?
- Cinemas?
- CD’s?
- X-Rays?
- MRI’s?

And any other technology you can think of that would ipmact society? Like medical devices etc?

Analog and Digital Circuit

analog digital circuit

Analog circuits

Most analog electronic appliances, such as radio receivers, are constructed from combinations of a few types of basic circuits. Analog circuits use a continuous range of voltage as opposed to discrete levels as in digital circuits.

The number of different analog circuits so far devised is huge, especially because a ‘circuit’ can be defined as anything from a single component, to systems containing thousands of components.

The Thyristor

Here the thyristor explanation form wikipedia:

The thyristor is a solid-state semiconductor device with four layers of alternating N and P-type material. They act as bistable switches, conducting when their gate receives a current pulse, and continue to conduct for as long as they are forward biased (that is, as long as the voltage across the device has not reversed).

Some sources define silicon controlled rectifiers and thyristors as synonymous.

The Thyristor’s Function

The thyristor is a four-layer semiconducting device, with each layer consisting of alternately N-type or P-type material, for example P-N-P-N. The main terminals, labeled anode and cathode, are across the full four layers, and the control terminal, called the gate, is attached to p-type material near to the cathode. (A variant called an SCS—Silicon Controlled Switch—brings all four layers out to terminals.) The operation of a thyristor can be understood in terms of a pair of tightly coupled bipolar junction transistors, arranged to cause the self-latching action:

Thyristor

Thyristors have three states:

  1. Reverse blocking mode — Voltage is applied in the direction that would be blocked by a diode
  2. Forward blocking mode — Voltage is applied in the direction that would cause a diode to conduct, but the thyristor has not yet been triggered into conduction
  3. Forward conducting mode — The thyristor has been triggered into conduction and will remain conducting until the forward current drops below a threshold value known as the “holding current”
